Main Product Image
Integrated all-in-one structure for solar street lighting projects.
Professional Solar Lighting Product
ZNSL-PRO-07-120W All-in-One Solar Street Light
120W solar street light with >210 lm/W efficiency for B2B outdoor projects.
ZANNOE ZNSL-PRO-07-120W is an all-in-one solar street light designed for urban roads, industrial areas, public outdoor lighting and engineering projects. It integrates the solar panel, LED light source, battery and controller in one compact engineering design for distributors, contractors and project owners.
120W Power
12.8V/120W Solar Panel
12.8V/65AH Battery
>210 lm/W Luminous Efficiency
IP65/IP66 Waterproof
3/5 Years Warranty
120W
Current model power
12.8V/120W
Solar panel
12.8V/65AH
Battery configuration
>210 lm/W
High luminous efficiency
IP65/IP66
Outdoor protection
3/5 Years
Warranty options
Product Gallery
ZNSL-PRO-07-120W Product Views
Visual references for reviewing the integrated housing, LED module arrangement, solar panel layout and application-ready structure before project inquiry.
Product Angle
Product housing and light head view for engineering buyers.
Series Lineup
Model range reference for 50W, 100W, 120W and 150W selection.
Component Detail
Close-up reference for LED chips, housing and integrated structure.
Parameter Image
Visual parameter reference, with final data confirmed by the table below.
Night Lighting Scene
Deep-blue project atmosphere for road and municipal lighting use.
All-Weather Performance
Built for Outdoor Engineering Environments
A deeper blue-black section highlights weather resistance while keeping the rest of the product page clean and readable for B2B decision makers.
IP65/IP66 Protection
Waterproof options support outdoor roads, parks, campuses and project sites.
Durable Housing
Integrated structure helps protect components during long-term outdoor use.
Solar Powered Operation
Panel and control configuration support lighting where grid wiring is difficult.
Project-Ready Use
Suitable for repeated B2B deployment across road and area lighting projects.
Product Details
Integrated Design Details
The ZNSL-PRO-07-120W combines clean structure, efficient LEDs and project-friendly installation for professional solar lighting supply.
High-Efficiency LED Module
Luminous efficiency is rated above 210 lm/W for this series.
Integrated Solar Panel
The ZNSL-PRO-07-120W model uses a 12.8V/120W solar panel.
120W Model Configuration
Designed for urban roads, industrial areas, public outdoor lighting and campus roads.
All-in-One Housing
Compact body integrates the major lighting and solar power components.
Installation Reference
Dimension and installation details can be confirmed before quotation.
B2B Application Fit
Designed for contractors, distributors and municipal outdoor lighting inquiries.
Technical Data
Technical Specifications
Confirmed technical data for the ZNSL-PRO-07-120W all-in-one solar street light. Final working mode and project configuration can be confirmed before order.
| Model | ZNSL-PRO-07-120W |
|---|---|
| Power | 120W |
| Dimensions | 429 x 1806 mm |
| Solar Panel | 12.8V/120W |
| Battery | 12.8V/65AH |
| Luminous Efficiency | >210 lm/W |
| Waterproof Rating | IP65/IP66 |
| Warranty | 3/5 Years |
| Brand | ZANNOE |
| Product Type | All-in-One Solar Street Light |
| Power Source | Solar photovoltaic |
|---|---|
| Material | Die-cast aluminum |
| CRI | Ra 70 |
| CCT | 2700K-6500K optional |
| Working Temperature | -25°C ~ 45°C |
| Battery Type | LiFePO4 battery |
| Control Method | Remote control / light control / motion sensor, depending on configuration |
| OEM/ODM | Available for suitable B2B orders |
| Certification | Available upon request; confirm before order |
| Origin | Guangdong, China |
For project orders, final working mode, package details and certification documents should be confirmed before order.
Dimension / Installation
Installation Reference for Project Planning
Use the model selection and installation image as a planning reference. Exact dimensions should be confirmed with the selected power model before production.
Series Dimension Reference
Suitable model and bracket details can be checked according to pole height, road width and target lighting area.
Pole-Mounted Installation
Designed for common pole-mounted outdoor solar street light projects.
120W Model Selection
Choose the ZNSL-PRO-07-120W model for urban roads, industrial areas, public outdoor lighting and campus roads.
Project Confirmation
Confirm local sunshine, installation height, working hours and waterproof requirement before final quotation.
Project Applications
Wide Applications
The ZNSL-PRO-07-120W is suitable for outdoor lighting projects where reliable solar operation and clean installation are important.
Urban Roads
Highways
Industrial Areas
Parking Lots
Parks & Campuses
Rural Areas
Product Advantages
Why Choose ZNSL-PRO-07-120W?
A professional all-in-one solar street light model for project buyers who need efficient lighting, clear specifications and supplier support.
All-in-One Design
Integrated structure helps simplify installation and project planning.
>210 lm/W Efficiency
High luminous efficiency supports stronger output with solar power.
IP65/IP66 Waterproof
Outdoor protection options for different site requirements.
120W Project Lighting
120W output for urban roads, industrial areas, public outdoor lighting and campus road projects.
12.8V/120W Solar Panel
Matched solar panel configuration for the ZNSL-PRO-07-120W model.
B2B Project Support
ZANNOE supports model selection, OEM/ODM discussion and project inquiry.
Product FAQ
FAQ
Common questions for distributors, contractors and project owners evaluating the ZNSL-PRO-07-120W solar street light.
What is the power of ZNSL-PRO-07-120W?
The ZNSL-PRO-07-120W model is rated at 120W and is suitable for urban roads, industrial areas and public outdoor lighting projects.
What solar panel is used?
The ZNSL-PRO-07-120W uses a 12.8V/120W solar panel.
What battery does it use?
The ZNSL-PRO-07-120W uses a 12.8V/65AH LiFePO4 battery configuration.
What waterproof rating is available?
The waterproof rating is IP65/IP66, depending on project and model configuration.
What warranty is available?
Warranty options are 3/5 years according to order terms and selected configuration.
Can ZANNOE support OEM/ODM and projects?
Yes. ZANNOE supports OEM/ODM discussion, project inquiry, model selection and B2B engineering support for suitable orders.
